Крюк -глин -крючок

Оглавление Показывать

Как ключевая связь между механизмом подъема вашего крана и критическими нагрузками, the Weihua Gantry Crane Hook embodies over 30 years of metallurgical innovation and rigorous quality control. Trusted in the world’s most demanding lifting environments, from Arctic logistics hubs to tropical megaports.

Крюк -глин -крючок

Gantry Crane Hook Technical Specifications (Typical Range – Customizable)

Параметр	Спецификация / Диапазон
Безопасная рабочая нагрузка (SWL)	1 тонна к 500+ тонны (Стандартный & Custom Capacities Available)
Материал	Высокопротивные сплавные стали (НАПРИМЕР., 34CRMO4, 42CRMO, 35CRMO, C-Mn Steel per standards)
Safety Standards	Iso 4301, Женский 1.001, ASME B30.10, ОТ 15400, ГБ/Т 10051.1, Маркировка CE
Доказательство нагрузки проверено	Обычно 125% к 200% SWL
Design Safety Factor	Minimum 4:1 (often higher, НАПРИМЕР., 5:1 for M6/FEM 1.001m)
Обработка поверхности	Электрооцинкованный, Горячая оцинковка, Окрашен, Stainless Steel (Айси 316)
Ротация	Fixed Eye, Plain Bushing Rotation, Sealed Anti-Friction Bearing Rotation (360°)
Защелка безопасности	Spring-Loaded or Bolt-Type (Стандартный)
Прослеживаемость	Unique serial number and test certificate provided

Крюк -глин -крючок

Основные функции & Преимущества

1. Uncompromising Strength & Долговечность:
- Премиум-материалы: Подделка из высокопроизводительной сплавной стали (НАПРИМЕР., Grade P, вопрос, С, or equivalent per FEM/DIN/ISO standards) for exceptional strength-to-weight ratio and resistance to deformation.
- Надежное строительство: Precision forging ensures superior grain structure flow, minimizing stress points and maximizing fatigue life under repeated heavy loads.
- Corrosion Resistance: Options include high-quality zinc plating (electro or hot-dip galvanizing), specialized coatings, or stainless steel variants for harsh environments (marine, chemical).
2. Повышенная безопасность & Надежность:
- Строгое тестирование: Every hook undergoes Non-Destructive Testing (NDT – Magnetic Particle, Dye Penetrant) and proof load testing (typically 1.5x – 2x SWL) to guarantee structural integrity and compliance with safety regulations (Iso 4301, Женский 1.001, ASME B30.10, ОТ 15400).
- Высокий коэффициент безопасности: Designed with a significant safety margin exceeding minimum regulatory requirements (НАПРИМЕР., 4:1, 5:1, or higher depending on classification).
- Secure Latch Options: Reliable spring-loaded safety latches or robust bolt-type latches included as standard to prevent accidental load disengagement.
3. Optimized Performance:
- Low Friction & Плавная операция: Precision-machined throat and saddle points minimize friction with slings and rigging, reducing wear and ensuring smooth load movement.
- Reduced Weight (Где применимо): Advanced forging techniques and design optimization result in lighter hooks without sacrificing strength, improving crane efficiency.
- Rotation Options: Available in fixed eye, standard rotation (plain bush/bearing), or low-friction sealed bearing rotation models (up to 360°) for effortless load positioning and reduced wire rope twisting.
4. Versatility for Every Task:
- Широкий ассортимент: Choose from various hook types:
  - Кованые одинарные крючки: Standard duty to ultra-heavy duty (SWL from 1 тонна до 500+ тонны).
  - Forged Ramshorn Крэйн двойной крюк: Ideal for balanced lifting with two sling legs (SWL from 1 тонна до 300+ тонны).
  - Laminated Hooks: Multiple steel plates for specific high-impact or specialized applications.
- Multiple Shank Configurations: Eye hooks, Clevis hooks, and hooks compatible with Weihua’s advanced trolley systems.

Крюк -глин -крючок

Why Choose Weihua Gantry Crane Hooks?

1. Global Leader: Leverage Weihua’s 30+ years of experience as a top crane manufacturer.
2. Гарантия качества: Stringent quality control at every stage, from raw material to final inspection.
3. Безопасность в первую очередь: Engineered and tested to exceed global safety standards.
4. Длительный срок службы: Durable construction minimizes downtime and replacement costs.
5. Индивидуальные решения: Tailor hook specifications (SWL, ротация, материал, coating) to your exact gantry crane and application needs.
6. Комплексная поддержка: Global network for parts, service, and technical expertise.

производитель

Gantry Crane Hook Applications

1. Port Container Handling & Bulk Material Terminals
2. Судостроение & Ремонтные площадки
3. Heavy Fabrication Workshops & Сталелитейные заводы
4. Large-Scale Construction Projects
5. Электростанции & Infrastructure Development
6. Heavy Machinery Installation & Обслуживание
7. Rail Yards & Логистические центры

Industry	Hook Solution	Ключевая функция
Ports/Terminals	RAMSHORN HOOK + TwistLock Adaptor	360° вращение + Iso 3874 container compatibility
Сталелитейные заводы	FORGED LADLE HOOK (M8 Duty)	Refractory heat shield (>800°C intermittent)
Wind Energy	MODULAR EYE HOOK with Dyneema® Sling Interface	Lightweight (35% mass reduction) for tower lifts
Offshore	DNV-GL Certified Hook with Zn-Ni Alloy Coating	Salt spray resistance >1,000 hrs (Iso 9227)
Автомобиль	Low-Profile Rotating Hook with RFID Tag	Collision avoidance in dense assembly lines

приложение

Advanced Safety Systems

Proactive Load Security:
- Smart Latch Monitoring: Optional IoT-enabled sensors detecting latch engagement status (output to crane control system).
- Anti-Swing Grooves: Machined throat geometry minimizes sling slippage during dynamic lifts.
Failure Prevention:
- Wear Indicators: Laser-etched wear limit markers on critical load zones.
- Overload Protection: RFID-tagged hooks with embedded load history (compatible with Weihua Crane Health Monitoring System).
