Double Girder EOT Crane

Apakah kren eot girder berganda?

Eot girder berganda (Perjalanan overhead elektrik) crane is a robust, overhead lifting system designed for heavy-duty material handling in industrial environments. Tidak seperti single girder EOT crane, it features two parallel main girders spanning the workspace, supported by end carriages that travel along elevated runways. This structure enables it to handle significantly higher loads—typically ranging from 10 tan ke 500 tons or more—making it ideal for demanding lifting tasks where precision, kestabilan, and durability are critical.

Powered by an electric motor, the double girder EOT crane operates via a hoist (mounted on a trolley) that moves along the girders, combined with runway travel for full coverage of the workspace. It is widely recognized as a reliable solution for streamlining operations in factories, gudang, dan industri berat.

Key Features of Double Girder EOT Cranes

Double girder EOT cranes stand out for their advanced design and performance, offering the following advantages:

• 1. Kapasiti beban tinggi: With two main girders distributing weight evenly, these cranes handle heavier loads (10t–500t+) compared to single girder models, suitable for lifting machinery, Gegelung keluli, dan komponen besar.
• 2. Enhanced Stability: The dual-girder structure minimizes deflection during lifting, ensuring stable operation even with maximum loads, reducing the risk of sway or imbalance.
• 3. Julat Kerja Lanjutan: The trolley runs along the full length of the girders, while the crane travels along the runway, providing comprehensive coverage of the workspace (customizable span lengths available).
• 4. Pembinaan Tahan Lama: Made from high-strength steel (Q235B or Q355B), the girders and components resist wear and corrosion, memastikan hayat perkhidmatan yang panjang (15–20 years with proper maintenance).
• 5. Konfigurasi yang disesuaikan: Adaptable to specific needs—options include speed control, Sistem anti-sway, kawalan jauh, Reka bentuk letupan-bukti, and specialized hoists (Mis., magnetic, cangkuk, or grab).
• 6. Operasi yang cekap: Electric drives deliver smooth, precise movement (angkat, troli, and crane travel speeds adjustable), reducing downtime and improving workflow efficiency.

Technical Parameters of Double Girder EOT Crane

Structural Components of Double Girder EOT Crane

A double girder EOT crane consists of several key components working together to ensure reliable lifting:

1. Gelang Utama

Two parallel box-type or I-beam steel girders forming the primary load-bearing structure, spanning the workspace.

2. Kereta akhir

Located at both ends of the main girders, equipped with wheels that travel along the runway rails, enabling the crane to move horizontally.

3. Angkat & Troli

The hoist (electric winch with hook, magnet, or grab) is mounted on a trolley, which travels along the main girders via rails, allowing vertical lifting and horizontal movement along the span.

4. Runway System

Elevated rails (installed on columns or walls) that guide the crane’s end carriages, defining the crane’s travel range.

5. Sistem elektrik

Termasuk motor (angkat, troli, perjalanan kren), panel kawalan, kabel, dan peranti keselamatan (overload sensors, had suis) to manage power and operations.

6. Pemandu teksi

Double Girder EOT Crane Manufacturing Process

Industry Applications of Double Girder EOT Cranes

Double girder EOT cranes are indispensable in industries requiring heavy lifting and precise material handling:

• 1. Keluli & Metalurgi: Lifting steel coils, jongkong, and forged parts in mills and foundries.
• 2. Pembuatan: Moving machinery, acuan, and large components in automotive, Aeroangkasa, and heavy equipment factories.
• 3. Pergudangan & Logistik: Loading/unloading heavy cargo, stacking bulk materials in ports, Kapal barang, and distribution centers.
• 4. Pembinaan: Lifting precast concrete, rasuk keluli, and construction machinery on job sites.
• 5. Tenaga & Perlombongan: Handling generators, transformer, and mining equipment in power plants and mines.
• 6. Pembuatan kapal: Assembling ship components and lifting heavy marine equipment.

FAQs About Double Girder EOT Cranes

Q1: What’s the difference between a double girder and single girder EOT crane?

A: Kren galang berganda mempunyai dua galang utama, menawarkan kapasiti beban yang lebih tinggi (10t+) dan kestabilan, suitable for heavy-duty use. Single girder cranes have one girder, ideal for lighter loads (up to 20t) and smaller workspaces.

S2: How often should a double girder EOT crane be maintained?

A: Pemeriksaan rutin (pemeriksaan harian untuk memakai, monthly lubrication) and annual professional maintenance are recommended to ensure safety and extend service life.

Q3: Can double girder EOT cranes be customized for special environments?

A: Ya. Options include explosion-proof designs (for hazardous areas), salutan tahan kakisan (for chemical plants), and high-temperature resistance (for foundries).

Q4: What safety standards do double girder EOT cranes comply with?

A: They adhere to international standards such as ISO, Fem, Dari, dan OSHA, with built-in safety features like overload protection and emergency stops.

S5: How long does it take to install a double girder EOT crane?

A: Installation time varies by size and complexity—typically 2–4 weeks for standard models, with longer timelines for custom or large-span systems.

Whether you need to lift heavy machinery in a factory or handle bulk materials in a port, our double girder EOT cranes deliver the strength, ketepatan, and reliability to optimize your operations. Contact us for a custom solution tailored to your needs.
