Cangkuk kren kapasiti tinggi 50 ton

Ciri -ciri utama & Spesifikasi

• 1. Kekuatan luar biasa & Ketahanan:

  • Bahan: Forged from high-tensile, low-alloy steel (Mis., Grade A, or equivalent per DIN/ISO/FEM standards).

  • Manufacturing: Precision forged under controlled conditions for superior grain structure and fatigue resistance.

  • Reka bentuk: Optimized profile for optimal load distribution and stress reduction, minimizing risk of deformation.

• 2. Enhanced Safety Systems:

  • Selak keselamatan bersepadu: Heavy-duty, spring-loaded safety latch securely retains slings, rantai, or shackles, preventing accidental disengagement (Standard feature, optional types available).

  • Smooth Surfaces: Machined bearing surfaces and throat area minimize wear on slings and rigging.

  • Pembukaan tekak: Generously sized to accommodate large shackles and multiple sling legs.

• 3. Rigorous Quality Assurance:

  • Proof Load Testing: Each individual high capacity crane hook 50 ton undergoes mandatory proof load testing significantly above its SWL (typically 125-200% of SWL) to verify structural integrity.

  • Ujian tidak merosakkan (Ndt): Subjected to Magnetic Particle Inspection (MPI) or Ultrasonic Testing (UT) to detect any subsurface flaws or defects.

  • Pensijilan: Compliant with international standards including FEM 1.001, Dari 15400/15401, ISO 7597, ASME B30.10, and carries relevant certifications (Mis., CE, GOST).

• 4. Precision Engineering:

  • Shank: Precision-machined shank ensures smooth rotation and optimal bearing contact within the cangkuk kren dan blok.

  • Latch Mechanism: Robust latch design ensures positive engagement and reliable operation even in harsh conditions.

  • Selesai: Protective coating (Mis., galvanized, painted) applied to resist corrosion and extend service life.

• 5. Fleksibiliti & Compatibility:

  • Designed for seamless integration with Weihua crane blocks and trolleys rated for 50-ton SWL.

  • Compatible with various rigging configurations (slings, rantai, spreader beams).

Crane Hook 50 Ton Technical Specifications

Ciri	Spesifikasi	Standard/Note
Beban kerja yang selamat (SWL)	50 Metric Tons (50,000 kg)	Primary Rating
Proof Load	Typically 62.5 – 100 Tan	Mandatory per hook
Bahan	High-Tensile Forged Steel	Mis., Grade A, 34CrMo4, etc.
Standard reka bentuk	Fem 1.001, Dari 15400/15401, ISO 7597, ASME B30.10	Compliant
Selak keselamatan	Dimuatkan musim bunga, Heavy-Duty	Standard
Testing	Beban bukti diuji, Ndt (MPI/UT)	On every hook
Perlindungan kakisan	Galvanized or Painted	Optional specifications available
Rotation	Swivel Type Standard	Ensures load stability

Where is the Weihua 50 Ton Crane Hook Essential?

This high capacity crane hook 50 ton is the workhorse for industries where lifting massive weights is routine:

• 1. Heavy Fabrication & Steel Mills: Handling large steel plates, coils, castings, and machinery.

• 2. Shipbuilding & Repair: Lifting ship sections, engines, and heavy components.

• 3. Ports & Terminals: Moving heavy containers, project cargo, and large machinery on/off vessels.

• 4. Power Generation: Installing and maintaining turbines, penjana, and transformers.

• 5. Mining & Heavy Equipment: Relocating large mining machinery, crushers, and excavators.

• 6. Large-Scale Construction: Positioning pre-cast concrete elements, bridge segments, and heavy plant equipment.

• 7. Aerospace: Handling large aircraft components and assemblies.

The Weihua Cangkuk kren kapasiti tinggi 50 ton represents the pinnacle of strength, keselamatan, and reliability for lifting critical heavy loads. Its robust forged construction, rigorous testing protocols, and adherence to international standards make it the trusted choice for industries where safety and performance under maximum load are non-negotiable. Equip your heavy-lifting cranes with the Weihua 50-ton hook for unparalleled confidence and productivity.

Ready to Specify or Learn More? Contact Weihua or your authorized distributor today to discuss your specific 50 ton lifting requirements and explore the full range of high-capacity crane solutions. Ensure your next heavy lift is anchored by the best.
