Foundry Crane Hook Heat Resistant

Weihua’s foundry crane hook heat resistant is engineered to endure high-temperature working conditions commonly found in steel mills, casting workshops, and smelting facilities. Manufactured with advanced materials and precision heat treatment processes, these hooks maintain structural integrity and load-bearing capacity even when exposed to intense heat.

Foundry Crane Hook Heat Resistant Key Features

• 1. Heat Resistance: Constructed with alloy steel or specialized heat-resistant materials, Weihua’s hooks withstand temperatures exceeding 300°C, ideal for ladle cranes and metallurgical operations.

• 2. High Strength: With optimized forging and heat treatment, the hook provides excellent mechanical performance under heavy loads.

• 3. Safety Design: Equipped with a safety latch and designed with proper throat openings to prevent load slippage during operation.

• 4. Wear Resistance: Treated for enhanced surface hardness to resist abrasion in demanding environments.

• 5. Customizable Options: Available in single or 크레인 더블 후크 types, tailored for specific foundry crane applications.

Technical Parameters – Weihua Foundry Crane Hook Heat Resistant

모델	Rated Load (t)	후크 유형	재료	Temp. Resistance	Throat Opening (mm)	안전 요인	인증
WH-FH05	5 톤 크레인 후크	Single	Heat-resistant alloy steel	≤ 300°C	45	5:1	ISO, CE
WH-FH10	10 톤 크레인 후크	Single	Cr-Mo steel, heat treated	≤ 350°C	55	5:1	ISO, CE, FEM
WH-FH20D	20 톤 크레인 후크	더블	Nickel-alloy steel	≤ 400°C	70	5:1	ISO, FEM
WH-FH50D	50	더블	Ultra-high strength steel	≤ 500°C	90	5:1	ISO, GOST
WH-FH100HD	100	Double Hook	Forged heat-proof alloy	≤ 500°C	120	5:1	CE, FEM, 안에 13155

메모: Custom options available for extreme-temperature (>500°C) applications.

Foundry Crane Hook Heat Resistant Applications

• Steel Plants

• Foundries

• Smelting Workshops

• Forging Operations

• High-Temperature Material Handling

Global Success Cases – Weihua Foundry Crane Hook Heat Resistant

Germany – ThyssenKrupp Steel Plant

In Duisburg, Weihua supplied heat resistant crane hooks for a ladle crane used in continuous casting operations. The hooks operate under temperatures around 400°C, successfully handling 150-ton molten metal ladles. The client praised the hooks’ performance and zero failure rate over two years of operation.

Brazil – Companhia Siderúrgica Nacional (CSN)

At CSN’s hot metal processing line, Weihua delivered a batch of foundry crane hook heat resistant components rated at 20 톤, specially treated for thermal resistance up to 450°C. The durability in South America’s humid and high-heat environment proved exceptional.

India – Tata Steel, Jamshedpur

Weihua worked with Tata Steel on a major plant upgrade. Our double-hook heat-resistant assemblies were used in a 100-ton overhead crane. These hooks perform seamlessly in the blast furnace bay, where ambient heat reaches 350°C.

Russia – Magnitogorsk Iron and Steel Works

Weihua installed a series of heat-resistant crane hooks rated for -40°C to +500°C temperature range. Their use in extreme thermal cycles showcased our hook’s exceptional metallurgical strength and crack resistance.

Why Choose Weihua?

Weihua is a globally recognized manufacturer of industrial cranes and lifting components. With decades of experience, our crane hook products are trusted in some of the world’s most demanding metallurgical environments. We offer not just equipment, but complete safety, technical support, and custom engineering solutions.
