Crane hook with pulley block

Engineered for maximum safety and efficiency, the Weihua Crane Hook with Pulley Block integrates robust construction with intelligent design. This critical lifting component ensures smooth load handling, reduced downtime, and extended service life across mining, construction, manufacturing, and logistics applications.

Technical Specifications (Typical Range – Customizable)

Parametro	Parameter content
Carico di lavoro sicuro (SWL)	1 Ton to 500+ tonnellate
Hook Material	Alloy Steel (e.g., 34CrMo4, 34CrNiMo6, 42Crmo), Grado 80, 100, or higher
Sheave Material	Steel (C45, 42Crmo) or Ductile Iron (GGG60)
Sheave Bearings	Sealed, Lubricated Anti-Friction Bearings
Fermo	Spring-Loaded Safety Latch (Standard)
Rotation	Fixed, Plain Bearing, or Ball Bearing Rotation Options
Finish	Primed (Standard), Hot-Dip Galvanized, Electro-Galvanized, or Painted
Standards	Iso 4301, Fem 9.511, ASME B30.10, DA 15400, GB/T 10051

Core components and superior design of crane hooks with pulley block

1. High-Strength Forged Hook:

   • Materiale: Manufactured from high-tensile alloy steel (e.g., Grado 80, 100, or higher according to demand), forged under strict conditions for superior grain structure and strength.

   • Cuscinetto per la sicurezza del gancio di gru: Standard equipped with a robust, spring-loaded safety latch to securely retain slings, chains, or lifting devices, preventing accidental disengagement.

   • Precision Machining: Precision-ground throat and shank surfaces ensure optimal load distribution and secure seating of lifting accessories.

   • Finishes: Shot blasted and primed for corrosion protection. Optional galvanization (hot-dip or electro) available for severe environments.

2. Optimized Pulley Block (Sheave Assembly):

   • Sheaves: Machined from high-grade steel or ductile iron, featuring smooth, accurately grooved profiles to minimize rope wear and maximize efficiency. Sealed, lubricated anti-friction bearings ensure effortless rotation.

   • Rigging: Side plates and cheek plates are fabricated from high-strength steel plate, designed for rigidity and resistance to bending or distortion under load.

   • Bushing/Pin Assembly: Precision-machined pins running on durable bushings or bearings provide smooth articulation and long service life.

   • Efficiency: The multi-sheave design provides significant mechanical advantage, reducing the force required from the hoist motor and wire rope for lifting heavy loads.

Technical highlights of crane hook with pulley block

Feature	Specifiche
Hook Material	High-tensile alloy steel (34CrMo4/42CrMo)
Sheave Material	Steel (C45) / Ductile Iron (GGG60)
Bearing System	Sealed lifelong lubricated bearings
Rotation	Fixed / 360° plain bearing / Ball bearing
Temperature Range	-40°C to +200°C (special grades available)
Certifications	Iso 4301, CE, GOST, GB/T 10051

Key Advantages

✅ Ultimate Safety Assurance

• Forged alloy steel hooks (Grado 80+/100+) with spring-loaded safety latches

• 150% proof load tested & certified to ISO 4301, Fem, ASME B30.10 standards

• Fail-safe design prevents accidental load disengagement

✅ Engineered for Efficiency

• Precision-machined sheaves with sealed anti-friction bearings

• Optimized groove geometry reduces rope wear by up to 40%

• Multi-sheave configurations (1-6 sheaves) for mechanical advantage

✅ Built for Extreme Durability

• Corrosion-resistant finishes: hot-dip galvanized or electro-coated options

• Impact-resistant forged steel construction

• Maintenance-free rotation systems (plain/ball bearing)

✅ Customizable Performance

• SWL range: 1–500+ tons

• Configurations: Eye/shank hooks, fixed/swivel rotation, latch variations

• Environment-adaptive: Standard / Arctic / Corrosion-resistant editions

Application of crane hook with pulley block

• 1. Overhead Bridge Cranes

• 2. Gantry Cranes

• 3. Jib Cranes

• 4. Monorail Systems

• 5. Construction Hoists

• 6. Port and Shipyard Cranes

• 7. Mining and Heavy Industry

• 8. Manufacturing and Fabrication Plants

• 9. Warehousing and Logistics

Why Partners Choose Weihua

• Proven Reliability: Weihua is a globally recognized leader in lifting solutions, trusted for quality and performance.

• Robust Engineering: Decades of experience designing components for the most demanding lifting environments.

• Rigorous Testing: Every component undergoes stringent quality control and load testing for guaranteed safety.

• Customization: Solutions tailored to your specific crane design, load capacity, and environmental needs.

• Global Support: Backed by Weihua’s extensive international service and parts network.

• Cost Efficiency: Reduced downtime, longer rope life, and lower maintenance costs through superior design and durability.

Made for Global Operations

Weihua Crane Hooks with Pulley Blocks are built to perform reliably in diverse conditions worldwide, from controlled factory floors to harsh outdoor industrial sites and marine environments.

Configure Your Solution

Contact your Weihua representative or authorized distributor today to discuss your specific crane hook and pulley block requirements. We provide expert engineering support to select the optimal configuration for your lifting application, ensuring maximum safety, efficienza, and productivity.
