Weihua Port Crane Hook – Reliable Lifting Solution for Port Operations

Port Crane Hook Product Features

• High Strength Materials: Manufactured from forged alloy steel with excellent tensile strength and toughness, ensuring long-lasting performance even under extreme port operation conditions.

• Corrosion-Resistant Finish: Equipped with anti-corrosion coatings or surface treatments to withstand harsh marine environments and saltwater exposure.

• Customizable Design: Available in various configurations including single hook, جرثقیل دو قلاب, and laminated types to suit different lifting tasks such as container handling, bulk cargo, and heavy equipment.

• Rotatable Hook Block: Optional 360° rotation hook block design allows for flexible maneuvering and precise cargo positioning, increasing operational efficiency.

• Advanced Safety Features: Incorporates safety latch systems, overload protection, and wear-resistant bushings to enhance operator and load safety.

• Compliance & Standards: Built to conform with international standards such as DIN, ایزو, and FEM, ensuring global usability and safety.

Weihua Port Crane Hook – Technical Parameters

مدل	Rated Load	نوع قلاب	مادی	دهانه قلاب (مگنی)	عامل ایمنی	چرخش	درمان سطحی	وزن (کلوت)
WH-PCH-10T	10 tons crane hook	قلاب	Forged Alloy Steel	60	5:1	اختیاری	Epoxy anti-rust coating	38
WH-PCH-20T	20 tons crane hook	قلاب	High-strength Steel	75	5:1	اختیاری	Zinc plated	52
WH-PCH-40T	40 تن	Double Hook	Forged Alloy Steel	95	5:1	Yes	Marine paint + galvanized	105
WH-PCH-60T	60 تن	Laminated Hook	Alloy Steel Plate	110	5:1	Yes	High-durability epoxy paint	188
WH-PCH-100T	100 تن	Laminated Hook	Alloy Steel Plate	135	5:1	Yes	Custom marine coating	310
WH-PCH-200T	200 تن	Laminated Hook	Quenched Alloy Steel	160	5:1	Yes	Double-layer anti-corrosion	670
WH-PCH-300T	300 تن	Laminated Hook	Special Alloy Steel	180	5:1	Yes	Customized per project	920

Customization Options

Weihua understands that every port has unique operational needs. That’s why we offer tailor-made port crane hook solutions to match your specific requirements. Our customization options include:

• 1. Load Capacity Range: From 5 tons to over 300 تن, accommodating both light and heavy-duty lifting tasks.

• 2. Hook Type Selection: Choose from single, double, or laminated hooks depending on the type of load and lifting environment.

• 3. Special Coatings: Anti-corrosion zinc plating, epoxy coating, or marine-grade paint for extended lifespan in coastal climates.

• 4. Smart Hook Integration: Optional integration with load cells, RFID tracking, and anti-sway systems for intelligent port management.

Port Crane Hook Applications

Weihua port crane hooks are widely used in:

• 1. Container terminals

• 2. Bulk cargo ports

• 3. Shipyards

• 4. Offshore platforms

• 5. Maritime logistics centers

They are compatible with a wide range of port cranes and are trusted by port operators around the world for their reliability and robust construction.

Port Crane Hook Successful Case

A major logistics hub in Southeast Asia upgraded its port crane system with Weihua’s double hook blocks designed for container spreaders. The project resulted in improved loading speed, reduced downtime, and extended hook service life due to Weihua’s anti-fatigue treatment and wear-resistant design.

تولید & Quality Control

Weihua adheres to strict quality control protocols throughout the entire production process to guarantee product safety and reliability.

• 1. CNC Machining & جعل: All hook components are precision-machined and heat-treated to enhance strength and fatigue resistance.

• 2. Non-Destructive Testing (NDT): Ultrasonic and magnetic particle inspection are performed to detect internal flaws or cracks.

• 3. تست بار: Each port crane hook undergoes a rigorous proof load test to ensure compliance with safety factor standards.

• 4. Traceability System: Every hook is marked with a unique ID number for full traceability of material origin, production batch, and inspection record.

Global Delivery & پشتیبانی پس از فروش

Weihua provides fast and reliable delivery services to major ports and logistics hubs worldwide. Our global service network ensures that technical support, spare parts, and maintenance can be accessed locally.

• Installation Guidance: On-site or remote support for hook assembly and integration into existing crane systems.

• Spare Parts Availability: Long-term supply of replacement parts such as pulleys, bushings, latches, and bearings.

• 24/7 Technical Support: Prompt assistance for troubleshooting, repair, and operational optimization.

Conclusion

The Weihua port crane hook is engineered for strength, امنیت, and efficiency — ideal for today’s demanding port environments. Whether handling containers, bulk goods, or oversized loads, Weihua’s crane hooks ensure smooth and secure lifting operations. Backed by decades of experience, cutting-edge technology, and a global service network, Weihua is your trusted partner for port crane solutions.
