Ramshorn crane hook for sale

Ramshorn Crane Hook Key Features & Benefits

• 1. Unparalleled Security: The unique twisted horn design creates a natural retaining barrier, ensuring lifting attachments stay securely in place throughout the lift, even during side pulls or dynamic movements.

• 2. Exceptional Strength & Durability: Forged from high-tensile Alloy Steel (typically Grade 100 or 80) under strict quality control. Precision heat treatment ensures optimal strength-to-weight ratio and superior toughness for heavy loads and harsh environments.

• 3. Corrosion Resistance: Standard models feature durable electro-galvanized (EG) coating. Optional Hot-Dip Galvanized (HDG) finish provides maximum corrosion protection for outdoor, marine, or chemical-exposed applications.

• 4. Safety Assured: Manufactured in compliance with rigorous international standards:

  • ASME B30.10 – Hooks
  • DIN 15401 / 15402 (European Standards)
  • CE Marked (where applicable)
  • ISO 9001 Quality Management Systems

• 5. Robust Design: Features a wide, deep throat opening for accommodating various sling configurations (shackles, chains, wire rope, synthetic slings) and large components. Thick cross-section provides outstanding resistance to bending and deformation.

• 6. Safety Latch Options: Available with robust spring-loaded safety latches as standard. Optional latch designs (positive locking, paddle latches) ensure the latch stays securely closed under load, providing an essential secondary safety layer.

• 7. Smooth Swiveling Action: Precision-machined thrust bearings (in swivel models) ensure smooth, low-friction rotation (360°), preventing load spin and reducing wire rope wear. Swivel lock options available.

• 8. Clear Load Rating: Each hook is permanently stamped with its Working Load Limit (WLL) and a unique serial number for traceability. Supplied with full test certification (Proof Load Tested).

• 9. Versatile Configurations:

  • Shank Types: Single Shank (Deck/Eye type), Double Shank (Clevis type).
  • Rotation: Fixed Shank, Swivel Crane Hooks, Swivel Shank.
  • WLL Range: Available in capacities from 1 Ton crane hook (1000 kg) up to 75 Tons (75,000 kg) or higher – specify your required capacity.

Ramshorn Crane Hook Technical Specifications

Parameter	Specifications
Working Load Limit (WLL)	1 ton to 75+ tons (1,000 kg to 75,000+ kg) Custom capacities available
Material	High-Tensile Alloy Steel *(Grade 80, 100, or equivalent per ASME/DIN)*
Design Standards	ASME B30.10, DIN 15401/15402, CE Marked, ISO 9001 Certified
Finish Options	– Electro-Galvanized (Standard) – Hot-Dip Galvanized (HDG, for corrosion resistance) – Painted (Custom)
Safety Latch	– Standard: Spring-Loaded Latch – Optional: Positive Locking Latch, Paddle Latch
Rotation Type	– Fixed Shank (Non-rotating) – Swivel Hook (360° rotation) – Swivel Shank
Shank Configuration	– Single Shank (Eye/Deck Type) – Double Shank (Clevis Type)
Bearing System	Precision Thrust Bearings (Swivel models) Swivel lock option available
Temperature Range	– Standard: -20°C to 200°C (-4°F to 392°F) – High-temp alloys available
Certification	Proof Load Tested (125% of WLL) + Test Certificate Supplied
Traceability	WLL & Serial Number Permanently Stamped on Hook
Compatible Attachments	Chains, Wire Ropes, Synthetic Slings, Shackles

Key Notes:

• 1. Customization: All parameters (WLL, finish, latch type, rotation) can be tailored to project needs.
• 2. Safety Factors: Hooks designed with a minimum 4:1 safety ratio (per ASME/DIN).
• 3. Corrosion Protection: HDG finish recommended for marine/offshore/chemical environments.
• 4. Load Testing: Each hook undergoes individual proof testing before certification.

Ramshorn Crane Hook Applications

• 1. Overhead Cranes & Gantry Cranes

• 2. Jib Cranes

• 3. Construction Hoists & Winches

• 4. Marine & Offshore Lifting

• 5. Heavy Rigging Operations

• 6. Foundries, Steel Mills, & Fabrication Shops

• 7. Mining & Material Handling

• 8. Warehouse & Logistics Centers

Why Choose Our Ramshorn Hooks?

• 1. Safety First: Engineered and certified for maximum load security.

• 2. Reliability You Can Trust: Precision forging and strict quality control ensure consistent performance.

• 3. Long Service Life: Superior materials and finishes resist wear, abrasion, and corrosion.

• 4. Global Compliance: Meets or exceeds major international safety standards.

• 5. Reduced Downtime: Durable construction minimizes maintenance and replacement needs.

Invest in the proven security and strength of our Ramshorn Crane Hooks. Contact our sales team for competitive pricing, specific model availability (including WLL, shank type, rotation, and finish), and fast shipping options.
